Vision X XPL Halo, a low profile LED light bar for extra discrete mounting on modern vehicles where much light is desired without taking up too much space and attention. XPL Halo has a single row of the same powerful 5 watt CREE LEDs that the PX ramp has and a cool Halo illumination effect that surrounds the reflectors.
5.5 years function warranty.
Robust aluminium/composite housing.
Unbreakable polycarbonate lens.
Moisture resistant pressure relief valve.
Heavy duty construction – can withstand vibrations up to 15.6 Grms.
Built in EMC interference filter (CISPR 25) – won’t disturb vehicles electronic systems.
Active temperature control with Prime Drive and ETM.
CE approved, RoHS certified.
Colour temperature 6000 Kelvin.
Temperature tested from -40°C to +80°C.
Relay wiring included.
Mounting feet included, side wing mounts is optional (Article No XPL-LEM).
Halo effect on a separate wire.
Light pattern: 10° Spot
Height: 52 mm
Width: 61 mm
Length: 1007 mm
Weight: 2.6 kg
LED: 30 x 5 W
Wattage: 150 W
Power consumption @12V: 12.5 A
Raw lumens: 16050
Effective lumens: 11235
Range @1Lux: 600 m
