Leírás

Features
  • LEDs: 10W Per LED
  • Housing Material: Aluminium
  • Light Colour Temp: 6000 Kelvin
  • Voltage: 11-32V DC
  • Amperage: 1.25A~11.25A@24V DC – 2.5A~22.5A@12V DC
  • Vibration Rating: 21 Grms
  • Lens Material: Polycarbonate
  • Xtreme Five Watt LED is Driven to 90% Efficiency
  • Proprietary IRIS Reflector Technology
  • Dual Mounting Standard
  • Weatherproof Deutsch Connector
  • Certifications: CE, RoHS, IEC 62471, E-Mark
Cikkszám Sugár meghatározása Nyers Lumen Hatékony Lumen Teljesítmény Súlya Méretek Nettó darabárak
XPR-H9M Tilted 9.711 lm(ea) 6.798 lm(ea) 90 Watt 2,31 kg 476x95x81 mm                        194 415 Ft
XPR-H12M Tilted 12.948 lm(ea) 9.064 lm(ea) 120 Watt 3,13 kg 611x95x81 mm                        244 158 Ft
XPR-H15M Tilted 16.185 lm(ea) 11.330 lm(ea) 150 Watt 3,95 kg 746x95x81 mm                        293 902 Ft
XPR-H18M Tilted 19.422 lm(ea) 13.595 lm(ea) 180 Watt 4,45 kg 881x95x81 mm                        343 646 Ft
XPR-H21M Tilted 22.659 lm(ea) 15.861 lm(ea) 210 Watt 5,26 kg 1.016x95x81 mm                        393 390 Ft
XPR-H24M Tilted 25.986 lm(ea) 18.127 lm(ea) 240 Watt 6,67 kg 1.150x95x81 mm                        443 134 Ft
XPR-H27M Tilted 29.133 lm(ea) 20.393 lm(ea) 270 Watt 6,90 kg 1.286x95x81 mm                        492 878 Ft
